UTi260B Thermal Imager
UNI-T Echo Thermal Imagers are 2nd generation products are more cost effective and also includes a wider temperature measurement range compared with the Classic series. Echo’s extra functions are digital camera and image fusion on selected models. This series is also very user friendly and rugged enough to pass IP65and 2m drop tests.
● 2.8" TFT screen
● Infrared resolution: 256 x 192
● Temperature measurement range: -20℃~550℃
● Photograph function with SD card storage
● PC analysis software
● Buzzer/flashlight alarm
● Real-time image transmission
● Auto capture of Hi/Low temperature
● Flashlight
● 1/4" tripod mounting hole
● IP65/2m drop proof
Specifications
Model UTi260B
Certifications CE/RoHS
Temperature range -20~550℃
IR resolution 256x192 pixel
Field of view (FOV) 56°x 42°
Thermal sensitivity (NETD) 50mk
Spatial resolution (IFOV) 3.8mrad
Frame rate 25Hz
Measurement accuracy ±2℃ or ±2% whichever is greater
Palettes 7
Emissivity Adjustable (0.01-1)
Focus Focus free
Display modes Thermal, blending, visible, PIP
Display 2.8”LCD
ROI (eliminates interference) √
General Characteristics
Power Li-ion battery (3.6V 5000mAh)
Product net weight Around 910g
Product net size 236mm x 75.5 mm x 86mm
Standard accessories Micro SD card, Type-C USB cable, English manual
Standard individual packing Gift box
