Product model: MX-210 household lathe (beads) Motor power: 750W 220V Chuck diameter: 125mm Spindle accuracy: 0.01-0.03mm Spindle taper: Mohs No. 3 / Mohs No. 5 Bed width: 100mm Trolley stroke: 55mm Turning Imperial Thread: 8-44TPI Maximum Machinable Diameter: 130mm Packing size: 800*390*470mm Speed: low 50-1250 high 100-2500RPM Tailstock taper: Morse No. 2 Tailstock sleeve stroke: 60mm Spindle through hole diameter: 38mm large through hole Center distance: 400mm Rotation diameter: 210mm Trunk travel: 75mm Turned Metric Thread: 0.5-3mm Lathe spindle center height: 108mm Net weight: 80kg application: Suitable for turning of metal, wood, jade, etc. Ideal for use in laboratories, workshops, engineering and education. External assistance can be provided for internal turning, threading, tapering, etc. Product advantages • Emergency stop: just close the red cover, very safe. • Zoomed telescopic device for visual viewing of the length of the telescoping handle, adjustable digitally or by lateral movement. • Spindle speed can be adjusted from 50 to 2500 RPM by adjusting the speed switch. • The machine adopts powerful all-metal gears, which are wear-resistant, durable, more precise, precise, precise and professional. • The saddle-tail scale has high precision, fine-tuning of the feed, and the telescopic sleeve scale is practical. • Automation tool with versatility and purpose, unlimited variables. feature • DC motor drive. • Stepless speed regulation. • Induction hardened slides. • All metal gears are free of any plastic parts. • Variable spindle speed 50-1250 / 100-2500RPM. • The spindle bearing adopts precision tapered roller bearing. • Guide rails are induction hardened and finish milled. • The spindle can be adjusted forward and reverse. • 600w high power, 300mm processing distance. • High-precision production of standard qualified works. Packaging Packaging: • 1 X Mini Lathe • 1 X 3 jaw collet (100mm) • 1 X splash guard • 1 X Chip Tray • 1 Toolbox • 1 X English User Manual
